SpringerBriefs in Architectural Design and Technology: Building Envelope

Zawidzki, Machi

This book explores the extremely modular systems that meet two criteria: they allow the creation of structurally sound free-form structures, and they are comprised of as few types of modules as possible. Divided into two parts, it presents Pipe-Z (PZ) and Truss-Z (TZ) systems. PZ is more fundamental and forms spatial mathematical knots by assembling one type of unit (PZM). The shape of PZ is controlled by relative twists of a sequence of congruent PZMs. TZ is a skeletal system for creating free-form pedestrian ramps and ramp networks among any number of terminals in space. TZ structures are composed of four variations of a single basic unit subjected to affine transformations (mirror reflection, rotation and combination of both).

Details

Published by: Springer

Publication Date: 2016-09-23

Format: Paperback

ISBN-13: 9789811013904

DOI: 10.1007/978-981-10-1391-1

Dimensions: 235cm x155cm

Pages: 121
