Dynamic Offset Compensated CMOS Amplifiers

Witte, Frerik; Makinwa, Kofi; Huijsing, Johan

Dynamic Offset-Compensated CMOS Amplifiers describes the theory, design and realization of dynamic offset compensated CMOS amplifiers. It focuses on the design of general-purpose wide-band operational amplifiers and instrumentation amplifiers.
Two offset compensation techniques are described: auto-zeroing and chopping. Several topologies are discussed, with which these techniques can be used in the design of wide-band dynamic offset-compensated amplifiers. Four implementations are discussed in detail: two low-offset wide-band operational amplifiers, a low-offset instrumentation amplifier, and a low-offset current-sense amplifier, which can sense the current drawn from supply voltages up to 28V .

Details

Published by: Springer

Publication Date: 2009-07-21

Format: Hardcover

ISBN-13: 9789048127559

DOI: 10.1007/978-90-481-2756-6

Dimensions: 235.0cm x155.0cm

Pages: 168.0
