Analog Circuits and Signal Processing: Design Methodology for Charge Pumps

Tanzawa, Toru

This book provides various design techniques for switched-capacitor on-chip high-voltage generators, including charge pump circuits, regulators, level shifters, references, and oscillators. Readers will see these techniques applied to system design in order to address the challenge of how the on-chip high-voltage generator is designed for Flash memories, LCD drivers, and other semiconductor devices to optimize the entire circuit area and power efficiency with a low voltage supply, while minimizing the cost. This new edition includes a variety of useful updates, including coverage of power efficiency and comprehensive optimization methodologies for DC-DC voltage multipliers, modeling of extremely low voltage Dickson charge pumps, and modeling and optimum design of AC-DC switched-capacitor multipliers for energy harvesting and power transfer for RFID.

Details

Published by: Springer

Publication Date: 2015-10-08

Format: Hardcover

ISBN-13: 9783319219745

DOI: 10.1007/978-3-319-21975-2

Dimensions: 235cm x155cm

Pages: 254
