SpringerBriefs in Applied Sciences and Technology

Ranz, Thomas

This revised, new edition presents the real analytic solutions for the “Disc with Circular Inclusion” under normal- and shear force at plane-strain state. The associated solution process, which was developed according to the principle of statically indeterminate systems, is documented extensively. The solutions are given in terms of mechanical quantities (deformations, strains and stresses). Due to the superposition of the solutions for normal force in x- and y-direction and shear force the plane strain-stress relation can be formulated. The validation of the real analytic solutions is carried out by numeric FEM solution results. Comparing the results of the finite and infinite disc there is, however, a very high correspondence of all mechanical quantities. Therefore it can be assumed the real analytical solutions are the exact solutions.

Details

Published by: Springer

Publication Date: 2021-04-30

Format: Paperback

ISBN-13: 9783030723965

DOI: 10.1007/978-3-030-72397-2

Dimensions: 235cm x155cm

Pages: 100
