Research on electronic transport in ultra small dimensions has been highly stimulated by the sensational developments in silicon technology and very large scale integration. The papers in this volume, however, have been influenced to no lesser extent by the advent of molecular beam epitaxy and metal/organic chemical vapor deposition which has made possible the control of semiconductor boundaries on a quantum level. This new control of boundary condi tions in ultra small electronic research is the mathematical reason for a whole set of innovative ideas. For the first time in the history of semiconductors, it is possible to design device functions from physical considerations involving ~ngstom scale dimensions. At the time the meeting was held, July 1982, it was one of the first strong signals of the powerful developments in this area. During the meeting, important questions have been answered concerning ballistic transport, Monte Carlo simulations of high field transport and other developments pertinent to new device concepts and the understanding of small devices from physics to function. The committee members want to express their deep appreciation to the speakers who have made the meeting a success. The USER pro ject of DOD has been a vital stimulous and thanks go to the Army Research Office and the Office of Naval Research for financial sup port. Urbana, January 1984 K. Hess, Conference Chairman J. R. Brews L. R. Cooper, Ex Officio D. K. Ferry H. L. Grubin G. J. Iafrate M. I. Nathan A. F.
Published by: Springer
Publication Date: 2011-10-02
Format: Paperback
ISBN-10: 9781461297147
ISBN-13: 9781461297147
DOI: 10.1007/978-1-4613-2777-6
Dimensions: 254cm x178cm
Pages: 360
